A NEW BREED OF TRAIL BIKE THAT BLENDS POWER, PERFORMANCE AND FLAT-OUT FUN. WITH ITS LIGHTWEIGHT COMPOSITE FRAME, PLUSH SUSPENSION AND NEW MOTOR TECHNOLOGY, YOU’LL NEVER WANT THE RIDE TO END.

Features

• SyncDrive Pro motor with 85Nm of torque creates powerful pedaling assistance even at low speeds.
• Lightweight, stiff Advanced-grade composite frame with 140mm of Maestro rear suspension travel and 150mm up front delivers confident handling and control on rough trails.
• Flip chip feature lets you change the head tube and seat tube angles, along with the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style.
• You can choose the low position for fast, aggressive terrain, or high for a more XC-oriented rider position.
• RideControl Go top tube integrated multi-function on/off button and RideControl Ergo 3 handlebar-mounted remote, which can be mounted on either grip, offer user-friendly controls and an uncluttered cockpit design.

Specifications

• Motor: Giant SyncDrive Pro2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technology
• Controller: Giant RideControl Ergo3, grip integrated remote
• Display: Giant RideControl GO, frame integrated LED console Optional wireless ANT+ display
• Battery: Giant EnergyPak 800Wh, 22700 Lithium cell technology, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production Giant EnergyPak Plus 250 range extender compatible
• Charger: Giant EnergyPak 6A smart charger, 60% in 3:00h
• Connectivity: Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
• Sizes: S, M, L, XL
• Colours: Airglow/Carbon Smoke
• Frame: Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system, 'Boost' 148x12 UDH rear axle, Giant EnergyPak Plus Range Extender Compatible
• Fork: Fox 36 Performance Elite Live Valve E-Tuned, 29er, 150mm travel, 44mm offset, Fit4 damper, Kabolt-X 110, electronic adaptive suspension, e-bike integrated
• Shock: Fox Float X Live Valve, 185x52.5mm Trunnion mount, electronic suspension, e-bike integrated
• Handlebar: Giant Contact SL 35, 35x780mm
• Grips: Giant Tactal Pro-E, single lock-on
• Stem: Giant Contact SL 35
• Seatpost: Tranz-X Rad+ dropper, 30,9mm, 30mm travel adjustable (S:120-150mm, M:140-170mm, L/XL:170-200mm)
• Saddle: Giant Romero, Neutral
• Pedals: Flatpedal
• Shifters: Shimano Deore XT
• Front Derailleur: MRP HD2 co-moulded chain guide
• Rear Derailleur: Shimano Deore XT, 12-speed, Shadow+
• Brakes: Shimano Deore XT, BR-M8120, 4-piston, hydraulic disc, 220mm
• Brake Levers: Shimano Deore XT, I-spec EV
• Cassette: Shimano CS-M7100, 10-51T, 12-speed
• Chain: KMC e.12 Turbo, EcoProteq, e-bike optimised
• Crankset: Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S:160mm, M/L: 165mm, XL:170mm)
• Bottom Bracket: n/a
• Rims: e-TRX Hookless Carbon Composite Clincher, 29", 30mm inner width
• Hubs: e-TRX 6 Bolt, Shimano Micro-spline, 110 x 15 [F], 148 x 12 [R] Thru Axle
• Tyres: Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra [F] Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+, 3C MaxxTerra [R]
• Extras: Tubeless kit (liquid, valves, levers, manual, tool) Inner tube supplied
• Lighting: Optional: - Giant Recon series e-bike lights available and direct connectable
• Lock: Torx 25 Battery Lock with built-in Torque limiter
• Weight: The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Geometry
