Specifications

• Frame: Overvolt Yamaha Supreme 5 alloy
• Fork: SR Suntour XCR 34 Air LO 15x110 29” 120mm travel
• Rear derailleur: Shimano Deore RD-M5100, 11-S Shadow +
• Crankset: Lapierre Overvolt 170mm, 34T narrow wide
• System: Yamaha PW-ST ‘’25kph’’ / Intube battery 630Wh / display A
• Sprocket: Shimano CS-M5100 11spd 11-51T
• Chain: KMC e11 Sport Silver -black 11s
• Brakes: Shimano M4100 hydraulic brakes
• Rotors: Shimano ASMRT30 203mm/203mm center lock
• Shiftlevers: Shimano Deore M5100 11s
• Headset: FSA Orbit 1.5 ZS NO.57SC
• Handlebar: Lapierre Alloy 6061 DB, Width: 740mm, Rise: 15mm, Ø: 31.8mm
• Grips: Velo ergo Lock-on
• Stem: Lapierre alloy, Ø: 31.8mm, L: 50mm
• Seatpost: Lapierre dropper, travel: 80mm (S), 100mm (M / L / XL)
• Saddle: Selle Royal Vivo Sport Men (145mm)
• Front hub: DA210, boost 15x110, 32H 6 center lock
• Rear hub: DA210, 4 sealed bearings, boost 12x148, 32H center lock
• Rims: Rodi Tryp 30 tubeless ready, 30-622 (29”) 32H
• Tires: WTB Ranger 2.6x29’’
• Pedals: XLC by VP
