From fast, rowdy descents to technical terrain, this progressive trail bike gives you active suspension, adjustable frame geometry, and everything you need to up your singletrack game.

This full-composite frame is engineered for 135mm of rear travel and 150mm up front. The Maestro rear suspension has a two-stage adjustable Advanced Forged Composite rocker arm with a trunnion-mount shock. A flip chip lets you choose either low or high frame geometry settings, which adjusts the headtube and seattube angle, along with the bottom bracket drop, to fine tune handling for your riding style and terrain.

Features

• 29er confidence and control: 29-inch wheels optimized to roll over technical terrain with balance and stability, giving you more momentum on tricky climbs and confidence to fly on fast singletrack descents. Added clearance for up to 2.5-inch tyres.
• Progressive suspension: Maestro rear suspension features a trunnion mount shock with a longer stroke and smoother feel. With 135mm of full rear-wheel travel (and 150mm up front), it features an Advanced Forged Composite upper rocker arm for increased stiffness and strength plus lower overall frame weight.
• Adjustable geometry: A flip chip lets you change the headtube and seattube angles, along with the bottom bracket height, to fine-tune the handling. You can choose the low position (65.5/77.2 head/seattube angle and 40mm BB drop) for fast, open terrain, or high (66.2/77.9 head/seattube angle and 30mm drop) for slower, tighter singletrack.

Specifications

• Sizes: S, M, L, XL
• Colours: Carbon / Hematite
• Frame: Advanced-Grade Composite front and rear triangles, 135mm Maestro suspension, flip chip, 12x148mm thru-axle
• Fork: Fox 36 Float Rhythm, 150mm, GRIP damper, Boost 15x110 Kabolt, 44mm offset, custom tuned for Giant
• Shock: Fox Float DPS Performance, 185/55, custom tuned for Giant
• Handlebar: Giant Contact TR35, 780x35mm, 20mm rise
• Grips: Giant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mm
• Stem: Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
• Seatpost: TranzX travel-adjustable dropper, remote S: 120-150mm travel / 30.9 x 459mm M: 140-170mm travel / 30.9 x 499mm L: 170-200mm travel / 30.9 x 525mm XL: 170-200mm travel / 30.9 x 525mm
• Saddle: Giant Romero SL
• Pedals: Not included
• Shifters: Shimano SLX SL-M7100, 1x12
• Front Derailleur: N/A
• Rear Derailleur: Shimano SLX RD-M7100
• Brakes: Shimano Deore BR-MT6120, hydraulic, Shimano RT-66 rotors [F]203mm, [R]180mm
• Brake Levers: Shimano Deore BL-M6100
• Cassette: Shimano SLX, 10x51
• Chain: KMC X-12
• Crankset: Shimano M511, 30t S:165mm, M:170mm, L:170mm, XL:170mm
• Bottom Bracket: Shimano, press fit
• Rims: Giant TRX 2 Carbon 29 WheelSystem, 30mm inner width
• Hubs: Giant TRX 2 Carbon 29 WheelSystem
• Spokes: Giant TRX 2 Carbon 29 WheelSystem
• Tyres: [F] Maxxis Minion DHF 29x2.5 WT, 3C MaxxTerra, EXO, TR [R] Maxxis Aggressor 29x2.4, EXO, TR, tubeless
• Extras: Factory set up tubeless, 2.5" max tyre size, 34t max chainring size, 3M tailgate protector
• Weight: The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Geometry
