SLX is ready to go wherever and whenever you want, whether it’s an all-day epic, the local cross country race, or a post-work ride with your buddies. It won’t let you down.

Features:

Lever

• Optimized lever axle position with additional contact point and refined ergonomics
• 10% stiffer than M8000 even under high temp conditions
• Quicker brake engagement with shorter free stroke
• Greater flexibility and action-optimized cockpit layout
• Toolless reach adjust
• Seamless braking raises rider concentration and enjoyment
• Stable and versatile high-performance brake control
• Rider tunable
• Simple set up and adjustment

Caliper

• Quicker Piston retraction
• Two piston
• Banjo type connection and inside hose routing
• Stable and versatile high-performance brake control
• Lightweight braking performance
• Quick and easy assembly

Specifications:

Lever

• Model Number: BL-M7100
• Series: SLX_M7100
• Brake Type: Hydraulic disc brake
• Clamp band: Open clamp band
• Compatible shifting lever mount: I-SPEC EV
• Funnel bleeding
• Hose joint: Straight
• J-kit option available
• Lever size (Finger): 2
• Oil: SHIMANO Mineral
• Reach adjust: Toolless
• Recommended brake caliper: BR-M7100, BR-M7120
• Servo wave mechanism

Caliper

• Model Number: BR-M7100
• Series: SLX_M7100
• Brake Type: Hydraulic disc brake
• Caliper fixing bolt: Anti loosen method Snap ring
• Caliper fixing bolt: Tool size 5 mm
• Hose joint: Banjo
• J-Kit spec (for OEM)
• Mount type (available for IS mount with mount adapter): Post-type
• Oil: SHIMANO Mineral
• One way bleeding
• Pad Option: J03A Resin (w/ fin), J04C Metal (w/ fin)
• Pad Standard: G03S Resin (w/o fin), G04S Metal (w/o fin)
• Pad mount: Pad axle
• Piston: 2
• Recommended brake rotor: SM-RT70
• Ice technology pad compatible caliper
