Specifications

• Frame: New Overvolt Explorer Integrated Bosch Supreme 5 alloy
• Fork: SR Suntour XCM 32 DS 15x100 15AH2 27,5” 80mm travel
• Rear derailleur: Shimano Deore RD-M4120, 10s Shadow +
• Crankset: LAPIERRE OVERVOLT BNI, 170mm + FSA Megatooth Chainring 38T
• System: Bosch Performance line “25kph” / Intube battery 500Wh / Purion display
• Sprocket: Shimano Deore CS-M4100 11-46T 10s
• Chain: KMC e10 Sport Silver -black 10s
• Brakes: Shimano MT200
• Rotors: Shimano SMRT10 180mm Center Lock (Front & Rear)
• Shiftlevers: Shimano Deore M4100 with optical gear display, 10s
• Headset: Feimin-H868PX, Black Finish, 1.1/8”
• Handlebar: Lapierre alloy 6061DB, Width: 680mm, Rise: 15mm, Backsweep : 25°, Ø: 31.8mm
• Grips: XLC Ergonomic grips
• Stem: Lapierre, 17°, Ø: 31.8mm, Length: 90mm
• Seatpost: XLC Suspension post, Ø: 31.6mm, Suspension : 40mm, Longueur : 350mm
• Saddle: Selle Royal Vivo ergo ective
• Front hub: Lapierre DA210, 2 Sealed Bearing, non-boost 15x100, 32H, Center Lock
• Rear hub: Lapierre DA210, 4 sealed bearings, boost 12x148, 32H, Center Lock
• Rims: Schürmann Yak25 32H, 584x25C Disc Rim 32H with Silver EyeletsWTB Intersector 58-584, Black Sidewall,
• Tires: Flat Guard, Dual DNA, 30TPI (27,5”) (Front & Rear)
• Pedals: VP VPE-461
• Accessories: Front light: Spanninga Axendo 30, 30 Lux, Rear Light: AXA JUNO 50mm, Fenders: Curana Aluminium Matt Black, Carrier: Lapierre Aluminium MIK Ready 25Kg
